Numerical simulation of involutes spline shaft in cold rolling forming

来源期刊：中南大学学报(英文版)2008年第z2期

论文作者：王志奎 张庆

文章页码：278 - 283

Key words：DEFORM-3D； involutes spline； cold rolling forming； numerical simulation； finite element

Abstract: Design of forming dies and whole process of simulation of cold rolling involutes spline can be realized by using of CAD software of PRO-E and CAE software of DEFORM-3D. Software DEFORM-3D provides an automatic and optimized remeshing function, especially for the large deformation. In order to use this function sufficiently, simulation of cold rolling involutes spline can be implemented indirectly. The relationship between die and workpiece, forming force and characteristic of deformation in the forming process of cold rolling involutes spline are analyzed and researched. Meanwhile, reliable proofs for the design of dies and deforming equipment are provided.
